Industry diesel generator set
YTO Line 8-305KVA
As one of the largest tractor and diesel engine manufacturers, YTO engine is renowned for their reliability and performance.
Yorking YTO Series diesel generator sets are distinguished by exceptional quality and cost-effectiveness. Covering a power range from 8kVA to 305kVA, these generator sets are suited for a wide range of industrial and commercial applications. Yorking YTO generator is designed for convenient maintenance and servicing, reducing downtime and maintenance costs while enhancing overall usability.
| Model | Prime | Standby | Engine | Alternator | Dimension(LxWxH)(MM) | ||||
| kVA | kW | kVA | kW | Model | Governor | Model | Silent type | ||
| Single phase | |||||||||
| YDY10E/S-E/S/SS | 8 | 8 | 9 | 9 | YD385D | M | Y164B/1P | 1660*850*1150 |  YDY10E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY12E/S-E/S/SS | 10 | 10 | 11 | 11 | YD480D | M | Y164C/1P | 1760*850*1150 | YDY12E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY15E/S-E/S/SS | 13 | 13 | 15 | 15 | YND485D | M | Y184ES/1P | 1760*850*1150 | YDY15E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY18E/S-E/S/SS | 16 | 16 | 18 | 18 | YSD490D | M | Y184ED/1P | 1890*900*1150 | YDY18E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY22E/S-E/S/SS | 20 | 20 | 22 | 22 | Y495D | M | Y184EF/1P | 1890*900*1150 | YDY22E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY28E/S-E/S/SS | 23 | 23 | 25 | 25 | Y4100D | M | Y184G/1P | 2218*930*1150 | YDY28E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| Three phase | |||||||||
| YDY12E3/S3-E/S3/SS3 | 11 | 8.8 | 12 | 10 | YD385D | M | Y164B | 1660*850*1150 | YDY12E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY15E3/S3-E/S3/SS3 | 13 | 10 | 15 | 12 | YD480D | M | Y164C | 1760*850*1150 | YDY15E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY18E3/S3-E/S3/SS3 | 16 | 13 | 18 | 14 | YND485D | M | Y184ES | 1760*850*1150 | YDY18E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY22E3/S3-E/S3/SS3 | 20 | 16 | 22 | 18 | YSD490D | M | Y184ED | 1890*900*1150 | YDY22E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY28E3/S3-E/S3/SS3 | 25 | 20 | 28 | 22 | Y495D | M | Y184EF | 1890*900*1150 | YDY28E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY33E3/S3-E/S3/SS3 | 30 | 24 | 33 | 26 | Y4100D | M | Y184G | 2218*930*1150 | YDY33E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY35E3/S3-E/S3/SS3 | 32 | 26 | 35 | 29 | Y4102D | M | Y184H | 2218*930*1150 | YDY35E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY40E3/S3-E/S3/SS3 | 37 | 30 | 41 | 33 | Y4105D | M | Y184H | 2218*930*1150 | YDY40E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY47E3/S3-E/S3/SS3 | 43 | 35 | 47 | 38 | Y4110D | E | Y224DS | 2520*1050*1200 | YDY47E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY53E3/S3-E/S3/SS3 | 48 | 38 | 53 | 42 | Y4102ZLD | M | Y224DS | 2520*1050*1200 | YDY53E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY61E3/S3-E/S3/SS3 | 55 | 44 | 61 | 49 | Y4105ZLD | E | Y224E | 2520*1050*1200 | YDY61E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY70E3/S3-E/S3/SS3 | 62 | 50 | 70 | 56 | YD4EZLD | E | Y224E | 2520*1050*1200 | YDY70E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY89E3/S3-E/S3/SS3 | 80 | 64 | 89 | 71 | Y4110ZLD | E | Y224G | 2520*1050*1390 | YDY89E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY100E3/S3-E/S3/SS3 | 90 | 72 | 100 | 80 | YD4GZLD | E | Y274CS | 2520*1100*1380 | YDY100E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY110E3/S3 | 100 | 80 | 110 | 88 | LR4M3L-D91BF-U2 | M | Y274C | 2660*1130*1520 | YDY110E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY123E3/S3 | 112 | 90 | 123 | 99 | LR4M3L-D91F-U2 | M | Y274DS | 2660*1130*1520 | YDY123E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY138E3/S3 | 125 | 100 | 138 | 110 | LR4M3L-D88EF-U2 | E | Y274DS | 2660*1130*1520 | YDY138E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY165E3/S3 | 150 | 120 | 165 | 132 | LR6A3L-D88EF-U2 | E | Y274FS | 3160*1100*1700 | YDY165E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY182E3/S3 | 165 | 132 | 182 | 145 | LR6M3L-D88EF-U2 | E | Y274G | 3160*1100*1700 | YDY182E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY220E3/S3 | 200 | 160 | 220 | 176 | LR6M3L-D60F196A-U2 | E | Y274H | 3650x1280x1950 | YDY220E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY248E3/S3 | 225 | 180 | 248 | 198 | YM6H4LF-D88EF-U2 | E | Y274J | 3650x1280x1950 | YDY248E3&S3 Technical Data-YTO-Yorking.pdf |
| Genset Model | Prime | Standby | Engine | Alternator | Dimension(LxWxH)(MM) | ||||
| kVA | kW | kVA | kW | Model | Governor | Model | Silent type | ||
| Single phase | |||||||||
| YDY11E/S-E/S/SS | 10 | 10 | 11 | 11 | YD385D | M | Y164B/1P | 1660*850*1150 | YDY11E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY13E/S-E/S/SS | 12 | 12 | 13 | 13 | YD480D | M | Y164C/1P | 1760*850*1150 | YDY13E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY18E/S-E/S/SS | 16 | 16 | 18 | 18 | YND485D | M | Y164D/1P | 1760*850*1150 | YDY18E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY23E/S-E/S/SS | 20 | 20 | 22 | 22 | YSD490D | M | Y184E/1P | 1890*900*1150 | YDY23E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY25E/S-E/S/SS | 22 | 22 | 24 | 24 | Y495D | M | Y184E/1P | 1890*900*1150 | YDY25E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| YDY30E/S-E/S/SS | 28 | 28 | 30 | 30 | Y4100D | M | Y184F/1P | 2218*930*1150 | YDY30E&S-E&S&SS Technical Data-YTO-Yorking.pdf |
| Three phase | |||||||||
| YDY14E3/S3-E/S3/SS3 | 12 | 10 | 14 | 11 | YD385D | M | Y164B | 1660*850*1150 | YDY14E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY17E3/S3-E/S3/SS3 | 15 | 12 | 17 | 13 | YD480D | M | Y164C | 1760*850*1150 | YDY17E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY23E3/S3-E/S3/SS3 | 20 | 16 | 22 | 18 | YND485D | M | Y184ES | 1760*850*1150 | YDY23E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY29E3/S3-E/S3/SS3 | 25 | 20 | 28 | 22 | YSD490D | M | Y184ED | 1890*900*1150 | YDY29E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY34E3/S3-E/S3/SS3 | 30 | 24 | 33 | 26 | Y495D | M | Y184EF | 1890*900*1150 | YDY34E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY39E3/S3-E/S3/SS3 | 34 | 28 | 39 | 31 | Y4100D | M | Y184G | 2218*930*1150 | YDY39E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY41E3/S3-E/S3/SS3 | 37 | 30 | 41 | 33 | Y4102D | M | Y184H | 2218*930*1150 | YDY41E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY50E3/S3-E/S3/SS3 | 45 | 36 | 50 | 40 | Y4105D | M | Y184H | 2218*930*1150 | YDY50E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY54E3/S3-E/S3/SS3 | 49 | 39 | 54 | 43 | Y4110D | E | Y224DS | 2520*1050*1200 | YDY54E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY60E3/S3-E/S3/SS3 | 54 | 43 | 59 | 47 | Y4102ZLD | M | Y224DS | 2520*1050*1200 | YDY60E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY66E3/S3-E/S3/SS3 | 60 | 48 | 66 | 53 | Y4105ZLD | E | Y224E | 2520*1050*1200 | YDY66E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY77E3/S3-E/S3/SS3 | 70 | 56 | 77 | 62 | YD4EZLD | E | Y224E | 2520*1050*1200 | YDY77E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY97E3/S3-E/S3/SS3 | 87 | 70 | 97 | 78 | Y4110ZLD | E | Y224G | 2520*1050*1390 | YDY97E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY110E3/S3-E/S3/SS3 | 100 | 80 | 110 | 88 | YD4GZLD | E | Y274CS | 2620*1100*1380 | YDY110E3&S3-E&S3&SS3 Technical Data-YTO-Yorking.pdf |
| YDY114E3/S3 | 104 | 83 | 114 | 91 | LR4M3L-D91BF-U2 | M | Y274CS | 2660*1130*1520 | YDY114E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY139E3/S3 | 125 | 100 | 138 | 110 | LR4M3L-D91F-U2 | M | Y274D | 2660*1130*1520 | YDY139E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY148E3/S3 | 135 | 108 | 148 | 118 | LR4M3L-D88EF-U2 | E | Y274D | 2660*1130*1520 | YDY148E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY183E3/S3 | 165 | 132 | 182 | 145 | LR6A3L-D88EF-U2 | E | Y274E | 3160*1100*1700 | YDY183E3&S3 Technical Data-YTO-Yorking .pdf |
| YDY200E3/S3 | 180 | 144 | 200 | 160 | LR6M3L-D88EF-U2 | E | Y274F | 3160*1100*1700 | YDY200E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY242E3/S3 | 220 | 176 | 242 | 194 | LR6M3L-D60F196A-U2 | E | Y274G | 3650x1280x1950 | YDY242E3&S3 Technical Data-YTO-Yorking.pdf |
| YDY276E3/S3 | 250 | 200 | 275 | 220 | YM6H4LF-D88EF-U2 | E | Y274J | 3650x1280x1950 | YDY276E3&S3 Technical Data-YTO-Yorking.pdf |
