Industry diesel generator set
HYUNDAI Line 167-1100KVA
Yorking diesel generator sets powered by Hyundai engines are ranged from 60kVA to 1120kVA. Hyundai is one of the world’s leading manufacturers of construction equipment, machine tools, and engines, playing a pivotal role in global infrastructure development and maintenance. With a well-established global network, Hyundai provides seamless support and service across all regions.
For this product line, Yorking select Leroy Somer alternators to further enhancing the reliability and performance of our diesel generator sets, ensuring consistent and efficient power generation across various applications, including the most demanding environments.
| Genset Model | Prime | Standby | Engine | Alternator | Dimension(LxWxH)(MM) | ||||
| kVA | kW | kVA | kW | Model | Governor | Leroy Somer | Silent type | ||
| YDD139E3/S3 | 126 | 100 | 139 | 111 | DP054CA | ECU | TAL-A44-E | 3250*1100*1750 | |
| YDD175E3/S3 | 159 | 127 | 175 | 140 | DP054CB | ECU | TAL-A44-K | 3250*1100*1750 | |
| YDD185E3/S3 | 168 | 134 | 185 | 148 | P086TI-1 | E | TAL-A44-K | 3250*1100*1750 | |
| YDD213E3/S3 | 200 | 160 | 213 | 170 | DP054CC | ECU | TAL-A44-M | 3650*1280*2050 | |
| YDD225E3/S3 | 200 | 160 | 225 | 180 | P086TI | E | TAL-A44-M | 3650*1280*2050 | |
| YDD239E3/S3 | 216 | 173 | 239 | 191 | DP086CA | ECU | TAL-A46-C | 3650*1280*2050 | |
| YDD254E3/S3 | 229 | 183 | 254 | 203 | DP086LA | E | TAL-A46-C | 3650*1280*2050 | |
| YDD256E3/S3 | 233 | 186 | 256 | 205 | DP086CB | ECU | TAL-A46-D | 3650*1280*2050 | |
| YDD275E3/S3 | 250 | 200 | 275 | 220 | DP086CC | ECU | TAL-A46-D | 3650*1280*2050 | |
| YDD308E3/S3 | 273 | 218 | 308 | 246 | P126TI | E | TAL-A46-E | 4100*1500*2200 | |
| YDD309E3/S3 | 280 | 224 | 309 | 247 | DP086CD | ECU | TAL-A46-F | 4100*1500*2200 | |
| YDD334E3/S3 | 300 | 240 | 334 | 267 | P126TI-II | E | TAL-A46-F | 4100*1500*2200 | |
| YDD336E3/S3 | 305 | 244 | 336 | 269 | DP086CE | ECU | TAL-A46-G | 4100*1500*2200 | |
| YDD344E3/S3 | 313 | 250 | 344 | 275 | DP126CA | ECU | TAL-A46-G | 4100*1500*2200 | |
| YDD390E3/S3 | 353 | 282 | 390 | 312 | DP126CB | ECU | TAL-A46-H | 4350*1600*2250 | |
| YDD406E3/S3 | 365 | 292 | 406 | 325 | DP126LB | E | TAL-A46-H | 4350*1600*2250 | |
| YDD450E3/S3 | 406 | 325 | 450 | 360 | DP126CD | ECU | TAL-A473-A | 4350*1600*2250 | |
| YDD468E3/S3 | 408 | 326 | 468 | 374 | P158LE | E | TAL-A473-A | 4350*1600*2250 | |
| YDD479E3/S3 | 434 | 347 | 479 | 383 | DP126CE | ECU | TAL-A473-B | 4350*1600*2250 | |
| YDD511E3/S3 | 462 | 370 | 511 | 409 | DP158LC | E | TAL-A473-C | 4450*1650*2250 | |
| YDD583E3/S3 | 529 | 423 | 583 | 466 | DP158LD | E | TAL-A473-D | 4450*1650*2250 | |
| YDD633E3/S3 | 574 | 459 | 633 | 506 | DP180LA | E | TAL-A473-E | 4650*1850*2350 | |
| YDD703E3/S3 | 636 | 509 | 703 | 562 | DP180LB | E | TAL-A473-F | 4650*1850*2350 | |
| YDD759E3/S3 | 689 | 551 | 759 | 607 | DP222LB | E | TAL-A49-B | 5050*1950*2500 | |
| YDD825E3/S3 | 750 | 600 | 825 | 660 | DP222LC | E | TAL-A49-B | 5050*1950*2500 | |
| YDD839E3/S3 | 763 | 610 | 839 | 671 | DP222CA | ECU | TAL-A49-C | 5150*1950*2520 | |
| YDD900E3/S3 | 813 | 650 | 900 | 720 | DP222CB | ECU | TAL-A49-C | 5150*1950*2520 | |
| YDD1000E3/S3 | 913 | 730 | 1000 | 800 | DP222CC | ECU | TAL-A49-D | 5150*1950*2520 | |
| Genset Model | Prime | Standby | Engine | Alternator | Dimension(LxWxH)(MM) | ||||
| kVA | kW | kVA | kW | Model | Governor | Leroy Somer | Silent type | ||
| YDD80E3/S3 | 72 | 58 | 80 | 64 | SP344CB | ECU | TAL-A42-H | 2660*1100*1520 | |
| YDD100E3/S3 | 91 | 73 | 100 | 80 | SP344CC | ECU | TAL-A44-C | 2660*1100*1520 | |
| YDD164E3/S3 | 148 | 118 | 164 | 131 | DP054CA | ECU | TAL-A44-E | 3250*1100*1750 | |
| YDD193E3/S3 | 174 | 139 | 193 | 154 | DP054CB | ECU | TAL-A44-J | 3250*1100*1750 | |
| YDD213E3/S3 | 193 | 154 | 213 | 170 | P086TI-1 | E | TAL-A44-K | 3250*1100*1750 | |
| YDD234E3/S3 | 219 | 175 | 234 | 187 | DP054CC | ECU | TAL-A44-L | 3650*1280*2050 | |
| YDD250E3/S3 | 229 | 183 | 250 | 200 | P086TI | E | TAL-A44-M | 3650*1280*2050 | |
| YDD260E3/S3 | 238 | 190 | 260 | 209 | DP086CA | ECU | TAL-A44-M | 3650*1280*2050 | |
| YDD285E3/S3 | 255 | 204 | 285 | 228 | DP086LA | E | TAL-A46-C | 3650*1280*2050 | |
| YDD293E3/S3 | 264 | 211 | 293 | 234 | DP086CB | ECU | TAL-A46-C | 3650*1280*2050 | |
| YDD321E3/S3 | 291 | 233 | 321 | 257 | DP086CC | ECU | TAL-A46-D | 3650*1280*2050 | |
| YDD334E3/S3 | 310 | 248 | 334 | 267 | P126TI | E | TAL-A46-D | 4100*1500*2200 | |
| YDD350E3/S3 | 318 | 254 | 350 | 280 | DP086CD | ECU | TAL-A46-E | 4100*1500*2200 | |
| YDD380E3/S3 | 345 | 276 | 380 | 304 | DP086CE | ECU | TAL-A46-F | 4100*1500*2200 | |
| YDD385E3/S3 | 344 | 275 | 385 | 308 | P126TI-II | E | TAL-A46-E | 4100*1500*2200 | |
| YDD396E3/S3 | 358 | 286 | 396 | 317 | DP126CA | ECU | TAL-A46-F | 4100*1500*2200 | |
| YDD426E3/S3 | 385 | 308 | 426 | 341 | DP126CB | ECU | TAL-A46-G | 4350*1600*2250 | |
| YDD444E3/S3 | 401 | 321 | 444 | 355 | DP126LB | E | TAL-A46-G | 4350*1600*2250 | |
| YDD490E3/S3 | 443 | 354 | 490 | 392 | DP126CD | ECU | TAL-A46-H | 4350*1600*2250 | |
| YDD510E3/S3 | 443 | 355 | 510 | 408 | P158LE | E | TAL-A46-H | 4350*1600*2250 | |
| YDD538E3/S3 | 479 | 383 | 538 | 430 | DP126CE | ECU | TAL-A473-A | 4350*1600*2250 | |
| YDD576E3/S3 | 520 | 416 | 576 | 461 | DP158LC | E | TAL-A473-B | 4450*1650*2250 | |
| YDD626E3/S3 | 566 | 453 | 626 | 501 | DP158LD | E | TAL-A473-C | 4450*1650*2250 | |
| YDD695E3/S3 | 630 | 504 | 695 | 556 | DP180LA | E | TAL-A473-D | 4650*1850*2350 | |
| YDD750E3/S3 | 678 | 543 | 750 | 600 | DP180LB | E | TAL-A473-D | 4650*1850*2350 | |
| YDD824E3/S3 | 745 | 596 | 824 | 659 | DP222LA | E | TAL-A473-E | 4650*1850*2350 | |
| YDD876E3/S3 | 793 | 635 | 876 | 701 | DP222LB | E | TAL-A473-F | 5050*1950*2500 | |
| YDD930E3/S3 | 842 | 674 | 930 | 744 | DP222LC | E | TAL-A49-B | 5050*1950*2500 | |
| YDD950E3/S3 | 863 | 690 | 950 | 760 | DP222CA | ECU | TAL-A49-B | 5050*1950*2500 | |
| YDD1025E3/S3 | 937 | 750 | 1025 | 820 | DP222CB | ECU | TAL-A49-C | 5050*1950*2500 | |
| YDD1120E3/S3 | 1000 | 800 | 1120 | 900 | DP222CC | ECU | TAL-A49-C | 5050*1950*2500 | |
